Accoustic wooden penels

Applications

These acoustic wall panels are perfect for any space where good speech privacy or speech intelligibility is important.

  • Auditoriums
  • Meeting Rooms
  • Theaters
  • Hotels

  • Offices
  • Lecture Halls
  • Educational Institutions
  • Airports
More Products

Wood
LINEAR ACOUSTIC PANEL

Acoustic panels

WoodTEC - LINEARO Series

Linearo Series Acoustic Panels feature elegant grooves on the front surface and precise perforations at the back, delivering both a premium look and excellent sound control. With their clean linear pattern, these panels bring a sleek, modern theme to walls and ceilings — making them a perfect solution for meeting rooms, lecture halls, and other professional spaces.

To meet different acoustic requirements, they are offered in multiple design variations, with customizable groove widths and spacing options. This ensures every project gets the right balance of performance and aesthetics.

Features

  • Reduces reverberation and echo
  • Low formaldehyde and moisture resistant
  • Highly aesthetic
  • High impact resistance
  • Better speech intelligibility
  • Washable and recyclable
  • Easily installable
  • Highly sustainable
CoreMDF Standard | MDF Fire rated | MDF Moisture Resistant
AbsorbentMineral wool (50mm)
Thickness16 mm | 18 mm | 20 mm
FinishesMelamine, Veneer, Painted
SizesStandard: 2430 x 160 mm Optional: 600×600 , 600×1200 , 517×1381 , 517×2400 , 128 x 2430, 197×2400 , 293×2400 , 197×1381 mm (custom sizes)
Density700 kg/m3
FlammabilityB-s2 d0
InstallationWalls: Omega metallic profiles, Clips, Wood battens
Ceilings: Standard system T24, Clips

Linearo Series – Type 1



Absorbent
(plenum)
125Hz250Hz500Hz1KHz2KHz4KHzNRC
50mm0.400.700.800.750.650.650.65
200mm0.650.650.650.700.700.700.70



Linearo Series – Type 2



Absorbent
(plenum)
125Hz250Hz500Hz1KHz2KHz4KHzNRC
50mm0.300.700.950.950.900.900.80
200mm0.750.850.850.900.950.950.90



Linearo Series – Type 3



Absorbent
(plenum)
125Hz250Hz500Hz1KHz2KHz4KHzNRC
50mm0.050.730.980.840.750.420.65
200mm0.560.860.720.890.750.420.70
Woodteclinear7
Woodteclinear8


Linearo Series

HOLE PITCH: 16 X 32mm, alternate
PERFORATION: 7.6%
HOLE DIAMETER: 10mm
NRC: 0.65 – 0.70
SPACING: 28mm
Woodteclinear7
Woodteclinear8


Linearo Series

Woodteclinear7
Woodteclinear8


Linearo Series

Wood
SLOTTED ACOUSTIC PANEL

SLOTTED ACOUSTIC PANEL

WoodTEC – SLOTTO Series
SLOTTO acoustic panels are designed to deliver excellent sound absorption while keeping the cost economical. These panels are available in multiple design options, making them a perfect fit for creating spaces that are both acoustically effective and visually appealing. Depending on the requirements, they can be customized with different groove patterns and spacing variations to match the design and acoustic needs of modern interiors.

Features

  • Reduces reverberation and echo
  • Low formaldehyde and moisture resistant
  • Highly aesthetic
  • High impact resistance
  • Better speech intelligibility
  • Washable and recyclable
  • Easily installable
  • Highly sustainable
Product Details
CoreMDF Standard | MDF Fire rated | MDF Moisture Resistant
AbsorbentMineral wool (50mm)
Thickness12 mm | 16 mm | 18 mm
FinishesMelamine, Veneer, Painted
SizesStandard: 600×600
Optional : 2400×1200, 2400×600, 1200×60, 1200×600, 1200×300
Density750 kg/m3
FlammabilityB-s2 d0
InstallationWalls: Omega metallic profiles, Clips, Wood battens
Ceilings: Standard system T24, Clips

Slotto Series – Type1



Absorbent
(plenum)
125Hz250Hz500Hz1KHz2KHz4KHzNRC
50mm0.050.730.980.900.850.760.85
200mm0.560.870.720.900.810.510.80



Slotto Series – Type2



Absorbent
(plenum)
125Hz250Hz500Hz1KHz2KHz4KHzNRC
50mm0.060.700.660.550.370.180.55
200mm0.670.740.600.600.370.180.60
