Line and round panel
Line and round panel
- Choices in wood finish and grooves, panel core and widths
- Curved ceilings | panelling is a possiblity with 128mm widths
- Rear perforations 10mm dia
| Parameters | Specifications |
|---|---|
| Type | Non-Grid |
| Finish | Woods |
| Core | Pinewood HDF Beige | Pink(FR) | Green(MR) | Ebony |
| Thickness (mm) | 16 |
| Size (mm) | 128|192 x 2440 |
| Density* (Kg/m3) | 700 |
| Weight (Kg/m2) | L16-9, L32-10.5, L64-11 |
| Acoustic Fleece** | 0.27mm, 63g/m2 |
| Fire** (Class) | 1 & P |
| NRC | L32-C18-0.65, L32-C40-0.75 |
| Thermal (W/mk) | na |
| Climate (0C, RH) | 50, 70 |
| Light (%) | 75 (Maple Arce) |
| Green (VOC, RC%) | E1, 25 |
| Warranty (Years) | 5 |
| Maintenance | Dry-wipe, Vacuum |
| Install Accessories – Ceiling | Strut SA25, WC25, MC45, CC25, CC18, SynthPF, Center & Edge Bracket by Anutone. Anchor bolt, soffit cleat, fasteners by others. |
| Install Accessories – Panelling | Strut CC10|CC25|CC50 with CC18, SynthPF, Stick S7, Center & Edge Bracket by Anutone. Fasteners by others. |
| Remarks | Store and use away from water, moisture, dampness, high humidity and termites. Ensure expansion joints @ >4m centres. For RH90 use Slats MR Green only. |
